WEAR PARTS
0463 641 001
- 37 -
© ESAB AB 2018
WEAR PARTS
Item Ordering no. Denomination Wire type Wire dimensions
1 0558 102 515 Brass outlet
assembly
N/A N/A
2
0464 635 880 Wire outlet guide
steel
Fe/SS/Flux
Cored
1.0mm–1.2mm
(0.040in.–0.045in.)
0464 634 880 Wire outlet guide
steel
Fe/SS/Flux
Cored
0.6mm–0.8mm
(0.023in.–0.030in.)
0464 598 880 Wire outlet guide
teflon
Aluminium 1.0mm–1.2mm
(0.040in.–0.045in.)
3 0558 102 329 Wire tension knob N/A N/A
4 0558 102 328 Wire inlet guide Fe/SS/Flux
Cored
0.6mm / 0.8mm / 0.9mm / 1.2mm
(0.023in. / 0.030in. / 0.035in. /
0.045in.)
5 0558 102 457 Key-drive shaft
crescent
N/A N/A
6
7977036 Feed roll "V" groove Fe/SS 0.6mm/0.8mm (0.023 in./0.030 in.)
7977660 Feed roll "V" groove Fe/SS 0.9mm/1.2mm (0.035 in./0.045 in.)
7977732 Feed roll "V"
knurled
Flux Cored 0.8mm/0.9mm (0.030 in./0.035 in.)
704277 Feed roll "V"
knurled
Flux Cored 1.0/1.2mm–1.4/1.6mm
(0.040in./0.063in.)
7977731 Feed roll "U" groove Aluminium 0.8mm/0.9mm (0.030 in./0.035 in.)
7977264 Feed roll "U" groove Aluminium 1.0mm/1.2mm (0.040 in./0.045 in.)
7 0558 102 518 Locking knob N/A N/A
8 0558 102 331 Pressure arm
complete assembly
N/A N/A
9 0558 102 550 Shoulder screw N/A N/A
10 0558 102 459 Euro adapter
locating screw
N/A N/A
11 0464 636 880 Euro adapter
assembly
N/A N/A
0558 102 528 Polarity change
cable
N/A N/A
0558 102 548 UI panel assembly N/A N/A
