SECTION 7 Replacement Parts
ESP 400C Plasma Power Source
7-3
Item No Qty Part Number Description Circuit Symbol
1 1 35749 Base
2 1 35751 Panel Right Side
3 1 35753 Cover Top
4 2 951032 Lamp LED Red 12V PL4, PL5
5 1 2134926 Lamp Indicator Amber PL3
6 2 951526 Lamp Neon White PL1, PL2
7 1 950122 Circuit Breaker 10A CB1
8 1 950715 Potentiometer 15K 2W R50
9 1 2062170 Knob
10 1 634518 Switch Toggle DPDT 2 pos S2
11 1 672508 Switch 10GL 3pst 2 pos S1
12 1 951061 Meter LED 5VDC 200MN #dp-350 VM
13 1 951061 Meter LED 5VDC 200MN #dp-350 AM
14 1 1006733 Conn Box Recp 19P J1
15 1 35752 Panel Left Side
16 1 35722 Panel Front
17 1 954932 Label PC Box Cover –ESP-400C
18 1
32338GY,BK,D
G
Plate Cover ESP-400C
19 1
35822GY,BK,D
G
Access Door
20 5 993426 Grommet Rubber 1.5 ID
21 1 634516 Switch Toggle SPDT 2 pos 10A 250V Q/D S4
22 1
35750GY,BK,D
G
Rear Panel
