1 Max (CW) 3 Pot Amps
2 Min (CCW)
10. Multifunction control - Voltage, down slope and arc force
The multifunction control knob is used to adjust voltage (MIG mode), down slope (LIFT TIG
mode) and arc force (MMA mode) depending on the welding mode selected.
NOTE!
The preview functionality provided on this power source is intended to act as a guide
only. Some differences may be observed between preview values and actual welding
values due to factors including the mode of welding, differences in consumables/gas
mixtures, individual welding techniques and the transfer mode of the welding arc (dip
versus spray transfer). Where exact settings are required (in the case of procedural
work), it is recommended that alternate measurement methods be utilized to ensure
output values are accurate.
