3 INTRODUCTION
The MEK 4C is an encapsulated wire feed unit with four roller feed.
The unit provides space for a 300 mm diameter wire reel and has a built--in
positioner.
For a wire feed unit to be complete it must be equipped either with a turnable,
counterbalance device or a carriage. A turnable or counterbalance device allow the
wire feed unit to be mounted on a pivot on the power source. A carriage allows the
wire feed unit to be moved easily over the floor or work table.
A wire feed unit and turnable or carriage can also be fitted with a support device and
suspended over the work place.
3.1 TECHNICAL SPECIFICATION
Dimensions lxwxh 630x245x490 mm
Weight 15 kg
Wire feed speed 1,9--25 m/min
Voltage 42 V 50--60 Hz
Power consumption 300 VA
Torch connection EURO
4 INSTALLATION
WARNING
This product is intended for industrial use. In a domestic environment this prod-
uct may cause radio interference. It is the users responsibility to take adequate
precautions.
