18
Replacement Parts List for Figure 5.1.
ITEM QTY. PART
NO. REQ'D. NO. DESCRIPTION
1 1 Handle and Cable Assembly:
998890 10-Ft., MT-200 (includes Handle 20829 and Cable 21097)
17715 12-Ft., MT-200 (includes Handle 20829 and Cable 21098)
998889 15-Ft., MT-200 (includes Handle 20829 and Cable 21099)
948075 10-Ft., MT-400 (includes Handle 20948 and Cable 21146)
17716 12-Ft., MT-400 (includes Handle 20948 and Cable 21147)
948076 15-Ft., MT-400 (includes Handle 20948 and Cable 21148)
18233 25-Ft., MT-400 (includes Handle 20948 and Cable 21149)
2 2 2062294* Terminal, (Supplied in Pkg. of 10)
3 2 950400* Clamp (Supplied in Pkg of 10)
4 1 948069* Plug Housing
5 2 2062344* Plug Terminal (Supplied in Pkg of 10)
6 2 493552* O-Ring .489ID x .070 Neopr 70A
7 1 * Setscrew #8-32 x 1/8"
8 1 * Hex Key 5/64" (Supplied - not shown)
9 1 20883* Adaptor, Inlet
12 1 998858 Switch Housing, MT-200
1 2075745 Switch Housing, MT-400
13 1 20885* End Cap, MT-200
1 2075215* End Cap, MT-400
14 1 998892 Wire Guide Insulator, MT-200
1 999475 Wire Guide Insulator, MT-400
15 1 185W31 Shoulder Ring
16 1 998859 Curved Wire Guide, MT-200 (Includes #8-32 x 3/16"
999453 Setscrew & a 5/64" Hex Key)
1 18234 Curved Wire Guide, MT-400 (Includes #8-32 x 3/16"
Setscrew & a 5/64" Hex Key)
17 1 2075220 Switch
18 1 999474 Front Insulator
19 1 2075214 Lever
20 1 2075219 Clamp
21A** 1 999452 Nozzle Adaptor (Includes O-Ring & 2-Friction Ring)
21B** 1 17983 Tip Adaptor
22** 1 - Contact Tip (See Figure 1.4 & Table 1.4.1)
23** 1 - Nozzle (See Figure 1.4 & Table 1.4.2)
24** 1 - Liner (See Table 1.4.3) includes:
O-Ring - 2064068 (Supplied in Pkg of 10)
* Item included with each Handle & Cable Assembly.
** Denotes Items not included with Basic Torch.
MT-200 Basic Torch Assembly, 10-Ft., 998888 MT-400 Basic Torch Assembly, 10-Ft., 999469
MT-200 Basic Torch Assembly, 12-Ft., 948921 MT-400 Basic Torch Assembly, 12-Ft., 948922
MT-200 Basic Torch Assembly, 15-Ft., 998887 MT-400 Basic Torch Assembly, 15-Ft., 999470
MT-400 Basic Torch Assembly, 25-Ft., 18232
