ESAB PSF 260C - Torch Neck PSF 420 Cw

SPARE PARTS LIST
DOKP4M4070
- 20-
© ESAB AB 2020
Torch neck PSF 420Cw
Item
Ordering no.
Denomination
300
0700 025 403
Torch neck PSF 420Cw
301
0700 025 472
Fume shroud PSF 420Cw
302
0700 025 478
Outer neck PSF 415C/420Cw
303
0700 025 477
Air regulator cpl. yellow big with screws
304
0700 025 480
Handle, black, cpl. for all fume torches Centrovac
w/o ill.
0700 025 481
Handle black, for RS3 fume torches Centrovac
305
0700 025 474
Micro switch, housed, yellow, cpl.
306
0700 025 479
Set of screws for handle
307
0700 025 487
Cable support W cpl.
308
0700 025 973
Quick connector
309
0700 025 975
Hose clamp with ring Ø 9.0
310
0700 025 951
Adaptor nut
311
0700 025 970
Central connector W
312
0700 200 098
Liner locking nut
313
0700 025 952
Cylinder head screw M4 × 6
314
0700 025 953
O-ring 4.0 × 1.0 mm
315
0700 025 974
Hose clamp with ring Ø 8.7
316
0700 025 976
Hose clamp with ring Ø 9.5
317
0700 025 485
Front connection for fume hose PSF 415C/420Cw
318
0700 025 993
PVC-Gas hose, black, 4.5 × 1.5 mm
319
0700 025 994
PVC hose, braided, black, 5 × 1.5 mm
320
306P384600
Fume extraction hose diam. 38 mm in coil
321
308P485115
Leather hose large 1,5 m long
324
0700 025 483
T-piece W for fume extr. hose PSF 420Cw cpl.
328
0700 025 473
Modul ESAB RS3 Centrovac
329
0700 025 490
Gas nozzle/fume shroud for PSF 420Cw
Item Ordering no. / 3 m Ordering no. / 4 m Ordering no. / 5 m Denomination
0700 025 983 0700 025 984 0700 025 985 Water-power cable
0700 025 986 0700 025 987 0700 025 988 Wire conduit
322 301P230431 301P230441 301P230451 Control cable cpl.
