4 TECHNICAL DATA
Welding torch PSF 260C
PSF 415C,
PSF 415C RS3
PSF 420Cw,
PSF 420Cw RS3
Type of cooling
Air
Air
Water
Permitted load at:
60% duty cycle*
100% duty cycle
Carbon dioxide CO
2
250 A 380 A 430 A
Mixed gas, Ar/CO
2
M21
225 A 325 A 430 A
Recommended gas
flow
8-12 l/min 10-18 l/min 10-20 l/min
Extraction volume:
40 m³/h 60 m³/h 53 m³/h
Differential pressure
1,4 Pa 4,0 Pa 2,9 Pa
Wire diameter 0.6-1.0 mm 0.8-1.6 mm 1.0-1.6 mm
Operating
temperature**
-10 °C to 40 °C -10 °C to 40 °C -10 °C to 40 °C
* The capacity may be reduced up to 30% when pulse welding.
** When using liquid cooled torches in freezing conditions, use an adequate cooling liquid.
