ESAB Warrior 500 - Page 22

22
Control Panel with Heat
REF
PART NO
DESCRIPTION
NOTE
1
415-155
FW, 1/2 SS
2
415-156
FW, 1/2 SS (Stand/Max OD)
3
580-010
Q.C. 1/4 FEM (Close)
4
555-184
Elbow 45,Street 1/4
5
410-205
MS, 10-32 x 1/2 Panphil SS
6
305-075
Switch, SPST 2-Posion Rocker
7
340-180
Boot, Seal Breaker
8
845-085
Control Panel
9
475-040
Gasket 1/8 x 1
10
400-150
Locknut 10 x 32 Nylon SS
11
703-009
Decal Warrior W/O Heat
12
340-162
Breaker 15A
13
360-015
1000 PSI Pressure Gauge
14
555-206
Elbow 90,1/4 FPT, Extruded
15
555-072
Close Nipple, 1/4
16
555-272
Hex Nipple, 1/4
17
555-208
Elbow 90,1/4 Street Extruded
18
305-120
Light, Heater
19
305-076
Switch, Lighted 2-Posion Rocker
