34
Pump
REF
PART
NO.
DESCRIPTION
NOTES:
1
555-456
Plug 3/8 MPT (countersunk)
2
581-065
Crimp FTNG, 3/8 x 1/4 MPT SVL
3A
572-125
Pulse Hose 3/8” x 45”
W/Heat &W/O Heat
3B
572-125
Pulse Hose 3/8” x 50”
W/O Heat
3C
572-125
Pulse Hose 3/8” x 9”
W/Heat
4
530-025
Regulator, 500 PSI
5
555-002
ADPT, 1/4 M x 1/4 F
6
425-005
Clamp, #8 Hose
7
555-208
Elbow 90, 1/4 Street Extruded
8
555-325
Hose Barb 90, 1/2 Barb x 1/4 MPT
9
400-135
Locknut, 1/4 x 20 Nylon Zinc
10
405-010
Bolt, 1/4 x 1 SS
11
415-125
FW, 1/4 SS
12
555-372
Hose Barb, 1/2 Barb x 3/8 MPT
13
555-024
Bushing, 3/8 M x 1/4 F
14
555-636
Tee, 1/4 Street Extruded
15
512-580
Pump, 500 PSI (c/w Motor & BRKT)
16
572-155
Polyspring Hose 1/2
17
465-081
Bracket , BPR
18
400-150
Locknut, 10-32 Nylon SS
