2
IMPORTANT: U-Leg is wider than U-support.
Make sure they are assembled exactly as
shown. If not, there will be a large gap between
table halves and table will not operate properly!
For aid in identifying hardware, see hardware identifier on page 9.
CAUTION:
4.Align the holes in the Large U-clips #34 and the U-clips #3
with pilot holes in table top assembly and secure with twenty
3
20
3
3
34
34
34
7
U-support
2
U-Leg
Figure 2
All screws shown
are (#20) sheet
metal screws.
Be sure that slot in the three U-clips #34 and the three
U-clips #3 all face the same direction (toward the
middle of the table with the U-support) as shown.
WHEN ASSEMBLING TABLE, IT IS EXTREMELY IMPORTANT THAT THE U-
CLIPS (#34) AND (#3) BE TURNED AS SHOWN HERE. IF U-CLIPS ARE
TURNED INCORRECTLY, YOU WILL DO IRREPARABLE DAMAGE TO YOUR
TABLE WHEN YOU ATTEMPT TO OPEN IT TO THE PLAYING POSITION.
If you want to see a video on how to position the U-Clips go to:
http://www.escaladesports.com/customer-service/videos.html
This end is the middle of the table
and has no stripe or pilot holes.
3
This end is the middle of the table
and has no stripe or pilot holes.
IMPORTANT:
four screws #20 as shown. All four holes in each U-Clip
must align with four pilot holes in top.
1.Lay table top #1 painted side down, on a smooth, flat
surface. Use the shipping container to protect the
painted surface of the table top.
2.
3.Put plastic caps #13 on the end of U-leg #2.
Figure 1
U-support
7
End Rail
Mounting
Holes
2
U-Leg
13
Plastic
Cap
13
Plastic
Cap
Align U-Support (#7) and U-Leg (#2) on Table Top as
shown in Figure 1. Note: “U” Leg is Larger and
wider than U-Support. The U-Leg should be
installed on the end of the table half with the
end rail mounting holes.
Table Top
1
To Next Page
