ESCALADE Stiga T8631F - Page 2

- 2 -
HARDWARE IDENTIFIER (To Scale)
H6 - 5mm x 13mm
Phillips Round Head
Screw (36 pcs)
H1 - 6mm x 60mm
Allen Head Bolt
(8 pcs)
H4 - 6mm x 55mm
Allen Head Bolt
(8 pcs)
H2 - 6mm x 18mm
Flat Washer
(36 pcs)
H7 - 6mm x 10mm
Plastic Spacer
(8 pcs)
H3 - 6mm
Lock Nut
(18 pcs)
H8 - Shoulder Washer
(2 pcs)
T1 - Allen
Wrench (1 pc)
T2 - Wrench (1 pc)
(Not to Scale)(Not to Scale)
H5 - 6mm x 45mm
Allen Head Bolt
(2 pcs)
