Table 1 Power Output Selection Guide (for
‘typical’
power display range)
Procedure Mode Condition Setting
CAUTION
Do not use a higher power setting than is necessary
General Normal cut Dry field 70 to 90
Pinpoint coag Dry field 25 to 45
Blend Dry field 45 to 70
Cardiothoracic Normal cut Wet field 70 to 90
Pinpoint coag Wet/dry field 30 to 55
Sternal oozing Spray coag Wet/dry field 35 to 60
Intercostal muscle Spray coag Wet/dry field 35 to 65
Gynaecology LLETZ Blend N-TZ (Displasia CIN I) 45 to 70
(Large Loop Excision of the Spray coag 40 to 55
Transformation Zone) Blend L-TZ (CIN I to II) 50 to 80
Spray coag 50 to 60
DEXC (Diathermy Specialist cut L-TZ (CIN II to III) 50 to 60
Excision of the cervix) Spray coag Microinvasive 45 to 60
Specialist cut TZ Identification 40 to 60
TCRE: TCAE Blend Normal endometrium 55 to 70
(Transcervical Resection of Specialist cut Spongio-endometrium 40 to 60
the Endometrium): (Ablation) Blend Suspect fibroid inv. 65 to 80
Spray coag Fundal ablation 50 to 65
Urology Specialist cut Spongio-prostate 135 to 160
Fibro/Muscular pros. 155 to 175
Normal cut Bladder tumour 115 to 135
Spray coag 40 to 60
Pinpoint coag Ball electrode 40 to 60
Plastic/burns Spray coag Eschar formation 40 to 50
Laparoscopic Blend Dry/wet field 50 to 70
cholecystectomy Spray coag Liver bed bleeding 55 to 65
Notes:
♦ Monopolar blend output mode can be used with advantage in many cutting procedures, particularly when only
a single (yellow) footswitch is being used.
♦ The blend mode produces less output power for a given control setting than normal cut, as shown on digital
power display (8 of illustration 11).
Bipolar micro Bipolar macro
Monopolar cut Monopolar blend Monopolar Specialist cut
Monopolar Pinpoint coag Monopolar spray coag
