eschmann TD830 - Performance Diagrams; Monopolar Cut, Blend, Specialist, Pinpoint, Spray Diagrams

E-IM54f P25/37
TD830
ELECTROSURGICAL UNIT
MONOPOLAR CUT (POWER v LOAD)
0
50
100
150
200
250
300
350
0 500 1000 1500 2000
Load resistance (ohms)
Power output (watts)
Half output control setting
Full output control setting
MONOPOLAR CUT DIAGRAMS
MONOPOLAR CUT (POWER v CONTROL)
0
50
100
150
200
250
300
012345678910
Output control setting (numerical value up to 10)
Power output (watts)
Load resistance 200 (ohms)
MONOPOLAR CUT (POWER v CONTROL)
0
50
100
150
200
250
300
0 25 50 75 100 125 150 175 200 225 250
Output control setting (typical pow er)
Power output (watts)
Load resistance 200 (ohms)
MONOPOLAR CUT (VOLTAGE v CONTROL)
0
200
400
600
800
1000
1200
0 25 50 75 100 125 150 175 200 225 250
Output control setting (typical pow er)
Peak output voltage (volts
)
Open circuit
MONOPOLAR CUT (VOLTAGE v CONTROL)
0
200
400
600
800
1000
1200
012345678910
Output control setting (numerical value up to 10)
Peak output voltage (volts)
Open circuit
