P26/37 E-IM54f
MONOPOLAR BLEND (POWER v LOAD)
0
50
100
150
200
250
300
0 500 1000 1500 2000
Load resistance (ohms)
Power output (watts)
Half output control setting
Full output control setting
MONOPOLAR BLEND (POWER v CONTROL)
0
40
80
120
160
200
012345678910
Output control setting (numerical value up to 10)
Power output (watts)
Load resistance 400 (ohms)
MONOPOLAR BLEND (POWER v CONTROL)
0
40
80
120
160
200
0 20 40 60 80 100 120 140 160 180 200
Output control setting (typical power)
Power output (watts)
Load resistance 400 (ohms)
MONOPOLAR BLEND DIAGRAMS
MONOPOLAR BLEND (VOLTAGE v CONTROL)
0
500
1000
1500
2000
2500
012345678910
Output control setting (numerical value up to 10)
Peak output voltage (volts)
Open circuit
MONOPOLAR BLEND (VOLTAGE v CONTROL)
0
500
1000
1500
2000
2500
0 20 40 60 80 100 120 140 160 180 200
Output control setting (typical power)
Peak output voltage (volts)
Open circuit
