eschmann TD830 - Page 31

E-IM54f P31/37
TD830
ELECTROSURGICAL UNIT
BIPOLAR MICRO DIAGRAMS
BIPOLAR MICRO (VOLTAGE v CONTROL)
0
40
80
120
160
012345678910
Output control setting (numerical value up to 10)
Peak output voltage (volts
)
Open circuit
BIPOLAR MICRO (VOLTAGE v CONTROL)
0
40
80
120
160
0 1.5 3 4.5 6 7.5 9 10.5 12 13.5 15
Output control setting (typical pow er)
Peak output voltage (volts)
Open circuit
BIPOLAR MICRO (POWER v CONTROL)
0
4
8
12
16
01.534.567.5910.51213.515
Output control setting (typical pow er)
Power output (watts)
Load resistance 100 (ohms)
BIPOLAR MICRO (POWER v CONTROL)
0
4
8
12
16
012345678910
Output control setting (numerical value up to 10)
Power output (watts)
Load resistance 100 (ohms)
BIPOLAR MICRO (POWER v LOAD)
0
4
8
12
16
20
0 200 400 600 800 1000
Load resistance (ohms)
Power output (watts)
Micro - Half output control setting
Micro - Full output control setting
