eschmann TD830 - Bipolar Macro and Micro Diagrams

P30/37 E-IM54f
BIPOLAR MACRO DIAGRAMS
BIPOLAR MACRO (VOLTAGE v CONTROL)
0
50
100
150
200
250
0 5 10 15 20 25 30 35 40 45 50
Output control setting (typical pow er)
Peak output voltage (volts)
Open circuit
BIPOLAR MACRO (VOLTAGE v CONTROL)
0
50
100
150
200
250
012345678910
Output control setting (numerical value up to 10)
Peak output voltage (volts)
Open circuit
BIPOLAR MACRO (POWER v CONTROL)
0
10
20
30
40
50
012345678910
Output control setting (numerical value up to 10)
Power output (watts)
Load resistance 100 (ohms)
BIPOLAR MACRO (POWER v CONTROL)
0
10
20
30
40
50
0 5 10 15 20 25 30 35 40 45 50
Output control setting (typical pow er)
Power output (watts)
Load resistance 100 (ohms)
BIPOLAR MACRO (POWER v LOAD)
0
10
20
30
40
50
0 200 400 600 800 1000
Load resistance (ohms)
Power output (watts)
Macro - Half output control setting
Macro - Full output control s etting
