E-IM54f P29/37
TD830
ELECTROSURGICAL UNIT
MONOPOLAR SPRAY COAG DIAGRAMS
MONOPOLAR SPRAY COAG (POWER v LOAD)
0
10
20
30
40
50
60
70
80
0 500 1000 1500 2000
Load resistance (ohms)
Power output (watts)
Half output control s etting
Full output control setting
MONOPOLAR SPRAY COAG (VOLTAGE v CONTROL)
0
500
1000
1500
2000
2500
3000
3500
4000
012345678910
Output control setting (numerical value up to 10)
Peak output voltage (volts)
Open circuit
MONOPOLAR SPRAY COAG (VOLTAGE v CONTROL)
0
500
1000
1500
2000
2500
3000
3500
4000
0 7.5 15 22.5 30 37.5 45 52.5 60 67.5 75
Output control setting (typical pow er)
Peak output voltage (volts)
Open circuit
MONOPOLAR SPRAY COAG (POWER v CONTROL)
0
20
40
60
80
012345678910
Output control setting (numerical value up to 10)
Power output (watts)
Load resistance 400 (ohms)
MONOPOLAR SPRAY COAG (POWER v CONTROL)
0
20
40
60
80
0 7.5 15 22.5 30 37.5 45 52.5 60 67.5 75
Output control setting (typical pow er)
Power output (watts)
Load resistance 400 (ohms)
