MONOPOLAR PINPOINT COAG (POWER v LOAD)
0
40
80
120
160
200
0 500 1000 1500 2000
Load resistance (ohms)
Power output (watts)
Half output control s etting
Full output control setting
MONOPOLAR PINPOINT COAG (POWER v CONTROL)
0
20
40
60
80
100
120
012345678910
Output control setting (numerical value up to 10)
Power output (watts)
Load resistance 400 (ohms)
MONOPOLAR PINPOINT COAG (POWER v CONTROL)
0
20
40
60
80
100
120
0 102030405060708090100
Output control setting (typical pow er)
Power output (watts)
Load resistance 400 (ohms)
MONOPOLAR PINPOINT COAG DIAGRAMS
MONOPOLAR PINPOINT COAG (VOLTAGE v CONTROL)
0
500
1000
1500
2000
2500
012345678910
Output control setting (numerical value up to 10)
Peak output voltage (volts)
Open circuit
MONOPOLAR PINPOINT COAG (VOLTAGE v CONTROL)
0
500
1000
1500
2000
2500
0 102030405060708090100
Output control setting (typical pow er)
Peak output voltage (volts
)
Open circuit
