Esco Lexicon - Chapter 7 - Engineering Details; Engineering Drawing and Component Identification

21
Ultra-Low Temperature Freezer
–
7.1 Engineering Drawing
1. PEP Cover
2. Temperature Controller
3. Door Handle
4. Main Door (White)
5. Main Door (Blue)
6. Condenser Grille
7. Chart Recorder Box
8. Thermal Break
9. Gasket
10. Stainless Steel Door Frame
11. Inner Door hinge
12. PEP
13. Inner Door
14. Embedded Pull
15. Access Port
16. Omega Bracket
17. Caster Wheel
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
