Chapter 2 • Characteristics :
CHAPTER 2
CHARACTERISTICS
This chapter deals with the Provocell™ Shaking Mixer/ Incubator operation, transportation, storage conditions, basic
parameters and performance.
2.1 Normal Operating Parameters
Environmental temperature: 10°C ~ 30°C
Relative humidity: ≤70%
Power supply: AC220V (or% 110v) ±22V 1A 50Hz/60Hz
2.2 Transportation and Storage Conditions
Ambient temperature: -20°C - +55°C
Relative humidity: ≤80%
2.3 Basic Parameters
Model / Parameters PV-PVC
Block Choice as ordered
Reference Code PVC-BLC-1 PVC-BLC-2 PVC-BLC-3 PVC-BLC-4 PVC-BLC-5 PVC-BLC-6 PVC-BLC-7
Optional Block 1.5ml × 40
(Standard)
0.2ml × 96 0.5ml × 54
15 × 24
Glass tube
Elisa plate 0.5ml x 26 +
1.5ml x 24
2ml × 40
Dimension(mm)(W×L×H) 295×265×170
Weight(kg) 8.5
2.4 Performance
Temperature range: Room temperature -14°C ~ 100°C.
Timer Range: 1~ 99h59min
Cooling Time: Room temperature - 10°C for 12min
Between 100°C to room temperature +10°C for 15min
Heating time: About 6°C/min; from 20°C to 100°C
Temperature control accuracy: ≤ ± 0.5 °C, 0-60°C; ≤ ± 1°C over 60°C
Temperature display resolution: 0.5°C
Temperature uniformity across the block: ≤ ± 0.5 °C, 0-60°C; ≤ ± 1°C over 60°C
Orbital speed: 300-1500rpm
Amplitude: 3mm
Note: Before power-on, please check the above operating conditions. Pay special attention to the voltage and the
power cable’s grounding
Note: The aluminum block can be customized to the user’s request. Please contact the distributor for futher information.
