ELECTRICAL SPECIFICATION
Accuracy is expressed as: ± (% of reading + no. of least significant
digits) at 23℃± 5℃and <75% R.H.
 Resistance (Parallel mode)
Test Frequency: 100 / 120 Hz
Accuracy
Range Maximum
Display
100 Hz/ 120Hz
Specified Note
10MΩ 9.999MΩ
0.6%+5 After open cal.
2000KΩ 1999.9KΩ
0.3%+3 After open cal.
200KΩ 199.99KΩ
0.3%+2 -
20KΩ 19.999KΩ
0.3%+2 -
2000Ω 1999.9Ω
0.3%+2 -
200Ω 199.99Ω
0.5%+3 After short cal.
20Ω 19.999Ω
0.6%+40 After short cal.
Test Frequency: 1K / 10K Hz
Accuracy
Range Maximum
Display
@1K Hz @10KHz
Specified Note
10 MΩ 9.999MΩ
0.6%+5
2.5%+10
*N2
After open cal.
2000 KΩ 1999.9KΩ
0.3%+5
0.8%+10
*N2
After open cal.
200 KΩ 199.99KΩ
0.3%+2 0.6%+5 -
20 KΩ 19.999KΩ
0.3%+2 0.6%+5 -
2000 Ω 1999.9 Ω
0.3%+2 0.6%+5 -
200 Ω 199.99 Ω
0.5%+3 1.2%+25 After short cal.
20 Ω 19.999 Ω
0.6%+40 1.2%+200 After short cal.
Note:
1. DUT (Device Under Test) & test lead should be used under
properly shielding condition.
2. The accuracy is specified for parallel mode in these ranges.
