Test Frequency: 10 KHz
Accuracy Range Maximum
Display
Capacitance DF
Spec. Note
50
μ
F 50.0
μ
F
2.0%+10
(DF<0.1)
8%+100/Cx+10
(DF<0.1)
After short
cal.
20
μ
F 19.999
μ
F
2.0%+6
(DF<0.2)
3.0+100/Cx+8
(DF<0.2)
After short
cal.
2000nF 1999.9nF 1.0%+5
(DF<0.5)
1.0%+100/Cx+6
(DF<0.5)
-
200nF 199.99nF 1.0%+5
(DF<0.5)
1.0%+100/Cx+6
(DF<0.5)
-
20nF 19.999nF 1.0%+5
(DF<0.5)
1.0%+100/Cx+6
(DF<0.5)
-
2000pF 1999.9pF 1.2%+6
(DF<0.5)
2.0%+100/Cx+6
(DF<0.5)
After open
cal.
200pF 199.99pF 2.0%+8
(DF<0.1)
4.0%+100/Cx+8
(DF<0.1)
After open
cal.
Notes:
1. Q Value is the reciprocal of DF.
2. DUT (Device Under Test) & test lead should be used under properly
shielding condition.
3. Cx=Counts of displayed C value, e.g. C=88.88
μ
F then Cx=8888.
4. This reading can be extended to 1999 MAX display with accuracy
not specified.
5. This reading can be extended to 19999 MAX display with accuracy
not specified.
6.
The accuracy for ceramic capacitor will be influenced depending on
the dielectric constant (K) of the material used to make the ceramic
capacitor. Related influence factors, please refer to the chapter
“Component dependency factors” on the accompanying CD-ROM.
