Escort ELC-3133A - Page 15

Test Frequency: 10 KHz
Accuracy (DF<0.5)
Range
Maximum
Display
Inductance DF
Spec.
Note
1000mH 999.9mH 2.0%+(Lx
/10000)%+ 8
*N4
1.5%+100/Lx+10 -
200mH 199.99mH 0.6%+(Lx
/10000)%+8
1.5%+100/Lx+10 -
20mH 19.999mH 0.6%+(Lx
/10000)%+10
2.0%+100/Lx+15 -
2000µH 1999.9µH
1.0%+(Lx
/10000)%+10
5.0%+100/Lx+20 After
short cal.
Notes:
1. Q Value is the reciprocal of DF.
2. This specification is based on the measurement performed by
specified test leads.
3.
Lx=counts of displayed L value, e.g. L=88.88H, then Lx=8888.
4. The accuracy is specified for series mode in this range.
15
