Escort ELC-3133A - Capacitance Measurement; Resistance Measurement

WARNING
To avoid electrical hazards, discharge the capacitor to be tested before
measuring.
FORCE SENSE
ON
OFF
SENSE FORCE
ALWAYS DISCHARGE THE CAPACITOR BEFORE TESTING
REC
HOLDRS232 D/Q/
P SAUTO
RANGEFREQ L/C/R
CAL
REL
θ
TOL
Red Clip
Figure-5. Capacitance Measurement.
FORCE SENSE
ON
OFF
SENSE FORCE
ALWAYS DISCHARGE THE CAPACITOR BEFORE TESTING
REC
HOLDRS232 D/Q/
P SAUTO
RANGEFREQ L/C/R
CAL
REL
θ
TOL
Red Clip
Figure-6. Resistance Measurement.
