Esoteric G-02 User Manual

12
Frequency setting options
The frequency setting options depend on the frequency mode (FREQ)
setting (see page 14).
When the frequency mode (FREQ) is set to 44:
OFF
No clock signal is output.
44.1k
44.1 kHz clock frequency is output.
88.2k
2 × 44.1 kHz (88.2 kHz) clock is output.
176.4k
4 × 44.1 kHz (176.4 kHz) clock is output.
22.5MHz
512 × 44.1 kHz (22.5792 MHz) clock is output.
100kHz
100 kHz clock is output.
10MHz
10 MHz clock is output.
A2 = A1
The A2 clock output matches the A1 clock output and will be
switched with the A1 setting.
This only appears for the A2 clock setting.
B2 = B1
C2 = C1
These settings for B2 and C2 function in the same way as the “A2 =
A1” setting.
When the frequency mode (FREQ) is set to 48:
OFF
No clock signal is output.
48kHz
48 kHz clock frequency is output.
96kHz
2 × 48 kHz (96 kHz) clock is output.
192kHz
4 × 48 kHz (192 kHz) clock is output.
24.5MHz
512 × 48 kHz (24.576 MHz) clock is output.
100kHz
100 kHz clock is output.
10MHz
10 MHz clock is output.
A2 = A1
The A2 clock output matches the A1 clock output and will be
switched with the A1 setting.
This only appears for the A2 clock setting.
B2 = B1
C2 = C1
These settings for B2 and C2 function in the same way as the “A2 =
A1” setting.
Clock output frequency setting (2)
