13
English
When the frequency mode (FREQ) is set to 44EXP:
OFF
No clock signal is output.
44.1k
44.1 kHz clock frequency is output.
88.2k
2 × 44.1 kHz (88.2 kHz) clock is output.
176.4k
4 × 44.1 kHz (176.4 kHz) clock is output.
352.8k
8 × 44.1 kHz (352.8 kHz) clock is output.
705.6k
16 × 44.1 kHz (705.6 kHz) clock is output.
1.4MHz
32 × 44.1 kHz (1.4112 MHz) clock is output.
2.8MHz
64 × 44.1 kHz (2.8224 MHz) clock is output.
5.6MHz
128 × 44.1 kHz (5.6448 MHz) clock is output.
11.2MHz
256 × 44.1 kHz (11.2896 MHz) clock is output.
22.5MHz
512 × 44.1 kHz (22.5792 MHz) clock is output.
100kHz
100 kHz clock is output.
10MHz
10 MHz clock is output.
A2 = A1
The A2 clock output matches the A1 clock output and will be
switched with the A1 setting.
This only appears for the A2 clock setting.
B2 = B1
C2 = C1
These settings for B2 and C2 function in the same way as the “A2 =
A1” setting.
When the frequency mode (FREQ) is set to 48EXP:
OFF
No clock signal is output.
48kHz
48 kHz clock frequency is output.
96kHz
2 × 48 kHz (96 kHz) clock is output.
192kHz
4 × 48 kHz (192 kHz) clock is output.
384kHz
8 × 48 kHz (384 kHz) clock is output.
768kHz
16 × 48 kHz (768 kHz) clock is output.
1.5MHz
32 × 48 kHz (1.536 MHz) clock is output.
3.0MHz
64 × 48 kHz (3.072 MHz) clock is output.
6.1MHz
128 × 48 kHz (6.144 MHz) clock is output.
12.2MHz
256 × 48 kHz (12.288 MHz) clock is output.
24.5MHz
512 × 48 kHz (24.576 MHz) clock is output.
100kHz
100 kHz clock is output.
10MHz
10 MHz clock is output.
A2 = A1
The A2 clock output matches the A1 clock output and will be
switched with the A1 setting.
This only appears for the A2 clock setting.
B2 = B1
C2 = C1
These settings for B2 and C2 function in the same way as the “A2 =
A1” setting.
