10
Troubleshooting
In case you experience any problem with this unit, please take
the time to look through this chart and see if you can solve the
problem yourself before you call your dealer.
No power
e Check the connection to the AC power supply. Check and
make sure the AC source is not a switched outlet and that,
if it is, the switch is turned on. Make sure there is power to
the AC outlet by plugging another item such as a lamp or
fan.
e Turn on the POWER switch.
Not synchronized
e Check to see if the current word clock output is supported
by the connected players. If necessary, select a word clock
frequency that is appropriate for the individual players.
There are occasions where the word clock available for
synchronization varies depending on the connection and
settings of the individual players. For details, consult the
manual for each player.
Desired frequency not selectable with A, B, and C buttons
e Select the proper fundamental frequency in FREQUENCY
MODE before operating the buttons.
If normal operation cannot be obtained, unplug the power
cord from the outlet and plug it again. This resets the
internal micro-computer which can be disturbed during
electrical storms, power interruptions, et cetera.
Specifications
Clock outputs
44.1 kHz lines . . . . . . . . . . . . . 44.1 kHz, 88.2 kHz, 176.4 kHz
48 kHz lines . . . . . . . . . . . . . . . . . . . 48 kHz, 96 kHz, 192 kHz
Universal clock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 kHz
Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . BNC coaxial
Output. . . . . . . . . . . . . . . . . rectangular wave (TTL level/75Ω)
Accuracy . . . . . . . Under ±0.1ppm (factory setting, ppm: 10
-6
)
Stabilized time of the output clock
When the G-03X is turned on. . . . . . . . . . . . About 2 minutes
When the FREQUENCY MODE button is pressed
Less than 30 seconds
Frequency input
Frequency . . . . . . . . . . . . . . . . . . . . 10 MHz (under ±10 ppm)
Terminal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . BNC coaxial
Input level . . . . . . . . . . . . . . . . Sine wave: 0.5 - 1.0 Vrms/50Ω
Rectangular wave: 1.5 - 3.0 Vpp/50Ω
General
Power supply
Europe model . . . . . . . . . . . . . . . . . . . . . AC 230 V, 50 Hz
U.S.A./Canada model. . . . . . . . . . . . . . . . AC 120 V, 60 Hz
Korea model . . . . . . . . . . . . . . . . . . . . . . AC 220 V, 60 Hz
Power consumption . . . . . . . 12 W (maximum), 7 W (nominal)
Weight. . . . . . . . . . . . . . . . . . . . . . . . . . . 9.1 kg (20 1/16 lbs)
External dimensions (W x H x D) . . . . . . 442 x 97.5 x 353 mm
(17 3/8” x 3 7/8” x 13 7/8”)
Operating temperature. . . . . . . . . . . . . . . . . . . . +5˚C - +35˚C
Accessories
Power cord x 1
Felt x 3
Warranty card x 1
Owner’s manual x 1
• Design and specifications are subject to change without
notice.
• Weight and dimensions are approximate.
• Illustrations may differ slightly from production models.
