7
WORD CLOCK OUT terminals
These terminals output precise word synchronization signals. Connect these OUT terminals to the
WORD SYNC IN terminals of the other digital equipment (CD player, D/A converter, etc.), using a
commercially available BNC coaxial cable (75 ohms).
< Each of the A, B, and C channels is switch-selectable between 1xFs, 2xFs, 4xFs and 100 kHz. So
you can, for example, connect an 88.2 kHz and a 176.4 kHz machine to the single G-03X and
synchronize them. Three buttons (A, B, and C) are provided on the front panel for each channel.
10MHz IN terminal
You can use the input of external 10MHz reference frequency. Connect this terminal to the
output terminal of the external 10MHz oscillator. Use a commercially available BNC coaxial cable
for connection.
When a 10 MHz signal is input to this terminal, the unit automatically generates a clock using an
external 10 MHz oscillator (instead of the internal crystal oscillator).
< If the output level of the oscillator is outside the allowable input range of this unit, the oscillator
cannot be used. Refer to the oscillator manual for information on the output level and accuracy
of the oscillator.
SIGNAL GND connection
Audio quality might be slightly improved by connecting the SIGNAL GND terminal of another
device using commercially available vinyl-coated wire.
< Note that this is NOT an electrical safety ground (earth).
Power cord receptacle
After all other connections have been made, insert the supplied AC power cord into this
receptacle, then connect the other end of the power cord into the wall socket.
< Ensure that your AC voltage corresponds to the voltage marked on the rear panel of the unit.
Consult a qualified electrician if you are in doubt.
< Use only the supplied Esoteric power cord. Use of other power cords may result in fire or electric
shock. Unplug the power cord when you are not going to use the unit for an extended period of
time.
D
C
B
A
