The system power supply can support up to 5 devices
1
2
3
MASTER=
7
OFF
6
ON
Only one monitor is set as the MASTER:
All other monitors set as SLAVE:
7
ON
SLAVE=
OFF
6
Power supply to be
with-in 100 meters
of monitor
No cable
or connection
polarity
Total cable run
should not exceed
150 meters between
door station and monitor
BUS
BUS
BUS
BUS
Address ID
01
Address ID
02
BUS
BUS
POWER
SUPPLY
240vAC
INPUT
The dipswitches are accessable
on the rear of the door station
Address ID
02
Address ID
03
Address ID
01
Address ID
04
MASTER
SLAVE
SLAVE
When using multiple
door stations ensure
that each unit has a
seperate Address ID
Refer to instructions supplied when
using different version of monitor
for MASTER/ SLAVE configuration
