ESP HDview - SYSTEM CONNECTION DIAGRAM

4
SYSTEM CONNECTION DIAGRAM
NB. The Video & Power connectors are not weatherproof. Please ensure the connections
are made internally, or housed in a suitable enclosure.
RekorHD DVR Manual.indd 4 09/05/2017 16:38:45
DVR Connections
Monitor
Router
HDMI Lead
Power Input
System Power
Supply
Power InputVideo Input
Power & Video
Input
System Camera
Mouse
Controller
