Esse Bakeheart - Consumable Parts

39
3. INSTALLATION INSTRUCTIONS
Item
Part No.
Description
Item
Part No.
Description
1
I-WH-100-
006US
Front LHS Brick
7
I-WH-100-
118US
Insulating Board
2
I-WH-100-
009US
Front RHS Brick
8
I-WH-100-
101US
Baffle
3
I-WH-100-
007US
Rear LHS Brick
9
ROPE/CUT.GRY
13MM
Door Rope
4
I-WH-100-
008US
Rear RHS Brick
10
Glass Rope 2
5
I-WH-100-
108US
Bottom Brick
11
500-IH-117
Ceramic Glass
6
I-WH-100-
109US
Rear Brick
12
Glass Rope 1
The Bolster Lid Rope Seals will also need replacing during the life of the cook
stove.
The above consumable parts can be ordered through your retailer. If your
retailer is unable to supply the consumable parts, or you would like to discuss
the availability of spare parts, please contact ESSE directly
4. CONSUMABLE PARTS
