22
2. OPERATING INSTRUCTIONS
7. Slacken the fixing bolt holding the
horizontal air pipe bracket in place, and
swing it clear.
8. Pull the two air pipes clear from the
firebox.
9. Remove the four side fire bricks
through the front of the cook stove,
insert the replacement bricks, then
reverse steps 1 – 8.
REPLACING THE FIRE GLASS
During the life of your cook stove, the fire door glass may need replacing. Do not
use the appliance if there is any sign of damage to the glass. Care should be taken
when replacing the fire door glass. Only use 4mm ceramic glass, appropriate for
use in wood fired stoves. The replacement glass should be 12
53
⁄64” x 9
29
⁄64“ (326
x 240mm). If the original glass is damaged, take extra care, using appropriate
hand and eye protection, and dispose of the broken glass appropriately.
To replace the glass…
