10
BE-MSFM
www.bestbuy.com/bestbuyessentials
Installing your adapters
Depending on the mounting-hole pattern on your TV, you may need to install the TV
plate adapters.
• Place the adapter washer over the adapter bolt, then screw on the adapter nut and
tighten with a lag bolt wrench.
Option 1: Installing the TV plate to TVs with a flat back
1 Align the TV plate with the screw holes on the back of the TV. Make sure that the
plate is level.
2 Place washers over the holes in the TV plate. Insert screws through the washers and
TV plate.
3 Tighten the screws until they are snug against the TV plate. Do not over tighten.
Note: The washer (I or J) size depends on the size of the screws used. Use the I washer
with screw B. Use the J washer with screw D or screw F.
Lag bolt wrench
Adapter
Adapter washer
Adapter nut
Flat back TV
TV Plate
With screw B
With screws D or F
