Estella 236ECEM2 - Parts Diagram

8
2
3
3
4
5
5
14
6
13
7
12
8
11 10 10 9
1
PARTS DIAGRAM
#
Descripon
1 Hot Water Knob
2 Espresso Brewing Unit Control Panel
3 Steam Knob
4 Brewing Group
5 Steam Tube
6 Main Power Switch
7 Drain Tray
#
Descripon
8 Foot
9 Sight Glass (Boiler Water Level Check Window)
10 Espresso Filter Holder
11 Cup Rack
12 Water Pressure Gauge
13 Steam Pressure Gauge
14 Hot Water Wand
