E21S Operation Manual
7
Parameter name
Unit
Range
Remarks
DLY
s
0~9.99
In case of single step, delay time for X axis
concession.
CUT
s
0~9.99
There is a delay time for the cutter goes to the
next work-step, after it leaves the top dead
center.
[Note] Only the parameter CutDelay En. is
set to 1, displaying this parameter.
F
None
0~3
Functions configure output.
PP
None
0~9999
Number of preset work piece.
CP
None
0~9999
Number of current work piece.
Step 3 Press , system will execute according to this program, as shown in Figure 2-3.
Figure 2-3 Single step operation page
----End
Operation example
On single-step program page, program back gauge position to 80.00mm, retract distance
to 50mm, concession waiting time to 2s, and work piece to 10.
Operation steps are shown in Table 2-2.
Table 2-2 Operation steps of single step example
Operation steps
Operation
Step 1
Click , select “XP” parameter.
Step 2
Input 80.00 by numerical key.
Step 3
Click , confirm setting of this parameter.
