Et DRIVE 1000 - Component Identification and Descriptions

5
1
2
3
4
5
15
14
13
12
10
9
6
7
8
7
6
18
6
7
8
7
6
17
17
16
15
11
Component idencaon and descripons.
Diagram
number
Descripon
Diagram
number
Descripon
1 Control card 10 Baseplate
2 Dashboard 11 ACDC power pack 220Vac input
3 Plug-in terminal connectors 12 Manual override access hatch
4 ACDC power pack 13 Manual override access hatch lock
5 Baery 14 Electric motor
6 Levelling and height adjusng bolts 15 Electric motor brush ports
7 Mounng bolts and nuts 16 Revoluon counter ring magnet
8 Security bracket kit mounng point 17 Ends of travel limits, reed switches
9 Cable inlets 18 Output drive pinion
359
410
237
0 - 10mm
355 364
92.5
16
305
