eta ePE-K - Ash Duct Cover and Recirculation Ducts

22 www.eta.co.at
Cleaning (customer) Cleaning and maintenance
Removing the cover on the ash duct
Remove the cover on the front of the ash duct.
Fig. 2-38: Cover
Cleaning the flue gas recirculation ducts
Remove the maintenance cover and the enclosed seal
for the primary air valve.
Fig. 2-39: Maintenance cover
Remove the ash from the flue gas duct with the clean-
ing brush and an ash vacuum.
Fig. 2-40: Flue gas duct
Check if the seal on the maintenance cover is intact
and replace if necessary. Re-attach the maintenance
cover.
Fig. 2-41: Maintenance cover
Mounting the cover on the ash duct
Re-install the cover on the front of the ash duct.
Fig. 2-42: Cover
