eta ePE-K - Pellet Hopper Checks

Cleaning and maintenance Maintenance (expert)
39
2.6.12 Check pellet hopper
Removing the collector from the pellet hopper
Remove the cover from the pellet hopper.
Fig. 2-98: Cover
Checking the stoker drive chains
Check the chain tension, see the following graphic.
Tension the chain by shifting the motor. Lubricate the
drive chains with chain spray.
Fig. 2-99: Stoker drive chains
Checking the position sensor clearance
Check the clearance between the sensor and the
washer. The clearance should be about 2 - 3 mm.
Fig. 2-100: Checking the clearance
Re-attaching the cover
Re-install the cover back onto the pellet hopper.
Fig. 2-101: Cover
