A – Robotic vacuum cleaner
A1 – Front bumper
A2 – Sensors against falling downstairs
A3 – Charging contacts
A4 – Storage battery compartment cover
A5 – Drive Wheels (Left / Right)
A6 – Front wheel
A7 – Side brushes
A8 – HYBRID BRUSH (combined slat and
bristle brush)
A9 – RUBBER BRUSH
A10 – FINE BRUSH
A11a – Main brush cover
A11b – Fine brush cover
A12 –RESET button
A13 – Service port
A14 – Disinfection UV light
A15 – Laser module
A16 – Wall detection sensor
B – Dirt hopper
C – Control panel
3.3 DUSTBIN
B
B1
B2
B3
B5
B4
B – Dirt hopper
B1 – Dirt tank release button
B2 – Dirt tank
B3 – Filter cover
B4 – HEPA filter
B5 – Foam filter
3.4 CONTROL PANEL
C1
C2
C – Control panel
C1 –ON /OFF/AUTO (automatic cleaning) / STOP (PAUSE) button
C2 – CHARGING / STOP (PAUSE) / LOCAL CLEANING button
