eta TIGER - Page 42

EN - 42
EN
Item Description Designation Quantity Match code
Cleaning tool G 1
ETA424200010
2 in 1 dirt container
(installed in the vacuum cleaner)
B 1
ETA424200020
Main brush
(installed in the vacuum cleaner)
A8 1
ETA424200050
Main brush cover
(installed in the vacuum cleaner)
A9 1
ETA424200040
-
Battery
(installed in the vacuum cleaner)
- 1
ETA424200270
3.2 ROBOTIC VACUUM CLEANER
A
A1
A2
A3
A4
A5
A6
A7
A8A9
A10
A11 C
B
F
A – Robotic vacuum cleaner
A1 – Front bumper
A2 – Sensors against falling downstairs
A3 – Charging contacts
A4 – Storage battery compartment cover
A5 – Drive Wheels (Left / Right)
A6 – Front wheel
A7 – Side brushes
A8 – Main brush
A9 – Main brush cover
A10 –RESET button
A11 – Laser module
B – Dirt container 2 in 1
C – Control panel
F – Mop extension
