EN - 44
EN
3.6 MOP EXTENSION
F
F1
F – Mop extension
F1 – Mop
4. PREPARATION FOR USE
Remove all packing material, remove vacuum cleaner and accessories.
Remove any adhesive films, stickers, paper or other protective elements from the vacuum
cleaner.
4.1 VACUUM CLEANER PREPARATION
According to use, install the 2 in 1 dirt container B and if you are going to mop, fill the tank
with clean water and install the mopping attachment F including the F1 mop. Install the
main brush A8 and the side brushes A7.
4.2 CHARGER STATION INSTALLATION
1. Place the charging station on the floor. Make sure there is enough space on the sides
of the base (at least 0.5 m) and in front of the base (at least 1.5). Don´t expose the
charging dock to sunshine.
2. Connect the cable to the charging station and then to the power supply.
