Examples Example with solar heating system
Circuit
board
Function blocks Description
PE-C 0 Twin TWIN pellet burner
In the boiler settings, adjust the installation
side.
PE-C 0 Standard store Pellet discharge conveyor
Standard screw Standard conveyor with screw
Circuit
board
Function blocks Description
SH-C 0 Boiler SH log boiler
TWIN pellet burner In the boiler settings, adjust the installation side
of the secondary engines.
SH-C 0 Sys System
Outside temperature sensor
Circuit
board
Function blocks Description
GM-C 0 Buffer Buffer storage tank
Solar charging For solar charging
Temp. sensor at buffer middle
Start relief for log boiler
GM-C 0 HWT Hot water tank
Charging pump for HWT
Solar charging For solar charging
GM-C 0 Heating circuit External heating circuit as radiator heating
Heating circuit pump
Heating circuit mixing valve
Digital room sensor
GM-C 0 Heating circuit External heating circuit as underfloor heating
Heating circuit pump
Heating circuit mixing valve
Digital room sensor
GM-C 0 Solar panel Solar heating system
2 tanks + diverter valve For switching between buffer and hot water tank
