Example with solar heating system Examples
Connections
= Type [Heating water]
= Type [SolarMedium]
= Type [Pellets]
= Type [SH-Twin]
Producers Consumers
SH-C 0: Boiler: Flow GM-C 0: Buffer: .
GM-C 0: Buffer: HC/HWT GM-C 0: HC: .
GM-C 0: HC2: .
GM-C 0: HW: .
GM-C 0: Solar: Tank 1 bottom GM-C 0: Buffer: Solar bottom
GM-C 0: Solar: Tank 2 bottom / Tank 1 top GM-C 0: HW: Solar bottom
PE-C 0: Store: Pellets PE-C 0: Twin: Fuel
PE-C 0: Twin: Flow SH-C 0: Boiler: Twin
