Example with solar heating system and stratified charging module Examples
Connections
= Type [Heating water]
= Type [SolarMedium]
= Type [Pellets]
= Type [SH-Twin]
Producers Consumers
SH-C 0: Boiler: Flow GM-C 1: Buffer1.1: .
GM-C 1: Buffer1.1: HC/HWT GM-C 0: HC: .
GM-C 0: HC2: .
GM-C 1: Buffer1.1: FWM GM-C 1: FWM1.1: .
GM-C 1: Solar1.1: Tank 1 bottom GM-C 1: Buffer1.1: Solar bottom
GM-C 1: Solar1.1: Tank 2 bottom / Tank 1 top GM-C 1: Buffer1.1: Solar top
PE-C 0: Store: Pellets PE-C 0: Twin: Fuel
PE-C 0: Twin: Flow SH-C 0: Boiler: Twin
