18 DSC2P Hardware Manual
ETEL Doc. - Hardware Manual # DSC2P / Ver H / 6/1/11
2.2.3 Ratings
There are four different types of DSC2P housed formats: the DSC2Px24-xxx, the DSC2Px34-xxx, the
DSC2Px44-xxx and the DSC2Px54-xxx.
All the specifications are given for an ambient temperature ranging from +15°C (59°F) to +30°C (86°F):
(1)
: With optional board mounted on the DSC2P, no external device connected to the I/O. The current can
change depending on the type(s) of encoder(s) used. A current equal to about twice the above-mentioned
value can be necessary to switch on the controller (because of the trigger pulse).
Remark: With PWM at 24 kHz, the current ripple in the motor is at 48 kHz (24 kHz with PWM at 12 kHz).
With two-phase motor, the current in 'motor phase 1- / 2-' (pin 3 of JC7 connector) is equal to
(√2 x motor phase 1+) or (√2 x motor phase 2+). Be careful to use the suitable cable diameter.
For an ambient temperature exceeding +30°C, a derating of 0.5 A per degree must be applied on
the above-mentioned current values.
The values given in the above-mentioned table are given for a sinusoidal output current with a
frequency higher than 0.5 Hz. The losses induced by a AC current are shared between the
transistors. A DC current heat up only some of the IGBTs and can induce their breakdown after
10 minutes if the current is near the maximum full load.
DSC2P POWER FEATURES for HOUSED FORMAT
Characteristics -Px24- -Px34- -Px44- -Px54-
Output
to the
motor
Voltage (up to) 400 VDC
Current range on
product label
3.75 Arms /
7.5 Arms (1s)
7.5 Arms /
15 Arms (1s)
15 Arms /
30 Arms (1s)
15 Arms /
40 Arms (0.5s)
PWM
at
24 kHz
Three-phase motor
Max. full load current
8.8 A
(6.2 Arms)
21 A
(14.8 Arms)
21 A
(14.8 Arms)
21 A
(14.8 Arms)
Three-phase motor
Max. overload current during 2 s
11 A
(7.7 Arms)
24.2 A
(17.1 Arms)
42 A / 1.5s
(29.6 Arms /
1.5s)
42 A / 1.5s
(29.6 Arms /
1.5s)
PWM
at
12 kHz
Three-phase motor
Max. full load current
8.8 A
(6.2 Arms)
21 A
(14.8 Arms)
28 A
(19.8 Arms)
28 A
(19.8 Arms)
Three-phase motor
Max. overload current during 2 s
11 A
(7.7 Arms)
24.2 A
(17.1 Arms)
48.4 Arms
(34.2 Arms)
56 A
(39.5 Arms)
PWM
at
24 kHz
Two-phase motor
Max. full load current
10 A
(7 Arms)
14 A
(9.8 Arms)
14
A
(9.8 Arms)
14 A
(9.8 Arms)
Two-phase motor
Max. overload current during 2 s
12 A / 10 s
(8.4 Arms)
21.2 A
(15 Arms)
28 A
(19.8 Arms)
28 A
(19.8 Arms)
PWM
at
12 kHz
Two-phase motor
Max. full load current
12 A
(8.4 Arms)
14 A
(9.8 Arms)
14 A
(9.8 Arms)
14 A
(9.8 Arms)
Two-phase motor
Max. overload current during 2 s
12 A / no time
limit (8.4 Arms)
24.2 A / 4 s
(17.1 Arms)
28 A / 4 s
(19.8 Arms)
28 A / 4 s
(19.8 Arms)
PWM
at
24 kHz
One-phase motor
Max. full load current
12 A
(8.4 Arms)
20 A
(14.1 Arms)
20 A
(14.1 Arms)
20 A
(14.1 Arms)
One-phase motor
Max. overload current during 2 s
12 A / no time
limit (8.4 Arms)
24.2 A
(17.1 Arms)
40 A
(28.2 Arms)
40 A
(28.2 Arms)
PWM
at
12 kHz
One-phase motor
Max. full load current
12 A
(8.4 Arms)
20 A
(14.1 Arms)
20 A
(14.1 Arms)
20 A
(14.1 Arms)
One-phase motor
Max. overload current during 2 s
12 A / no time
limit (8.4 Arms)
24.2 A / 4 s
(17.1 Arms)
40 A / 4 s
(28.2 Arms)
40 A / 4 s
(28.2 Arms)
Power supply
input
AC voltage (single or three-phase) 84 - 280 VAC
Max. AC current at 1x or 3x 84 - 280 VAC 1x or 3x 6 A
Max. inrush current per phase at 280 VAC 15 Apeak
Auxiliary supply
input
DC voltage 24 VDC
Max. current at 24 VDC
850 mA
(1)
Maximum current measurable by the controller 12.5 A 25 A 50 A 66.67 A
