DSC2P Hardware Manual 21
2.3 Ordering information
Here is the ordering information describing the meaning of each digit present on the label of the DSC2P:
Remark: Not all the combinations are possible.
D S C 2 P121-111X-0 0 0
Family product:
DSC2P: 400VDC position controller
Encoder type:
1 = Analog (1Vptp) or absolute (EnDat 2.1) or TTL
Power output:
1 = 3.75 Arms (no time limit)
2 = 3.75 Arms / 7.5 Arms (1s)
3 = 5 Arms (for 10F rack) or 7.5 Arms (for 14F rack) /
15 Arms (1s)
4 = 10 Arms (for 10F rack) or 15 Arms (for 14F rack) /
30 Arms (1s)
5 = 15 Arms / 40 Arms (0.5s)
Assembly:
1 = Rack format with plate heat sink and frontplate of 10F
(available with power output 1, 2, 3 and 4, with relay option 1)
2 = Rack format with extruded heat sink and frontplate of 14F
(available with power output 3, 4 and 5, with relay option 1)
4 = Housed format (available with power output 2, 3, 4 and 5,
with relay option 3 or 4, and auxiliary supply input 2)
Relay option:
1 = Without relay (only for rack format assembly 1 and 2)
3 = With power stage relay (only for housed format assembly 4)
4 = With motor’s short-circuit relay AND power stage relay (only
for housed format assembly 4)
Auxiliary supply input:
1 = 120 - 340VDC
2 = 24 - 55VDC (only +24VDC for housed format assembly 4)
Standard option:
1 = Not UL recognized
2 = UL recognized
By default, the DSC2P is delivered without UL recognition
Hardware version
Customer modification
000 means ’standard product’
