Eternity Plus M26 - Page 5

3
HOT
WATER
OUTLET
COLD
WATER
INLET
GAS
INLET
ENSUITE
LAUNDRY
BATHROOM
KITCHEN
CONTROLLER 1
(OPTIONAL)
CONTROLLER 2
(OPTIONAL)
CONTROLLER 3
(OPTIONAL)
MIN. 2 METRES
(FROM HOT OUTLET TO NEAREST HOT WATER TAP/OUTLET)
50ºC PRESET UNIT
HOT
WATER
OUTLET
COLD
WATER
INLET
GAS
INLET
ENSUITE
LAUNDRY
BATHROOM
KITCHEN
CONTROLLER 1
(OPTIONAL)
CONTROLLER 2
(OPTIONAL)
CONTROLLER 3
(OPTIONAL)
MIN. 2 METRES
(FROM HOT OUTLET TO NEAREST HOT WATER TAP/OUTLET)
70ºC PRESET UNIT
(NOTE: TCD - TEMPERATURE CONTROL DEVICE)
NOTE: M20 UNIT SHOWN IN ABOVE EXAMPLES
TCD
