Eternity Plus M26 - Dimensions and Connection Points (M26)

7
GAS INLET
3/4” (NOM 20mm)
PRESSURE RELIEF
VALVE & WATER
INLET FILTER
COLD WATER INLET
1/2” (NOM 15mm)
REMOTE
CONTROLLER
CABLE POINT
HOT WATER
OUTLET
1/2” (NOM 15mm)
3.2 DIMENSIONS AND CONNECTION POINTS (M26)
195
176
385
413
595 645 645
390
