CHAPTER 1.TECHNICAL SPECIFICATIONS AND DATA
1-1 Technical specifications and data
DG6LE
Generator
Generator Type Single phase AC generator
Frequency 60 Hz
AC Rated power
5.0 kW
AC Voltage 120/240 V
DC Voltage 12 V
DC Current 8.3 A
Speed 3600 rpm
Power factor(cosΦ) 1.0
Phase type Single-phase
Number of poles 2
Excitation Self-excitation voltage
Diesel Engine
Engine model ETQ186FA
Type Single-cylinder,vertical,4-stroke,air-cooled,direct injection
Output
Continuous 6.7 Kw / 9 HP
Maximum 7.45 kW / 10 HP
Bore×Stroke 86×72 mm / 3.39×2.83 in
Displacement 418 cc / 25.51 cu in
Cooling system Forced air cooling by flywheel fan
Lubricating system Pressure splash,duplex type lubrication
Lube-oil capacity 1.65 L / 55.79 fl oz
Starting system Recoil manual start / Electric start
Fuel tank capacity 12 L / 3.17 gal
Net weight 112 kg / 247 lb
Dimensions(L×W×H) 865×690×810 mm / 34.1×27.2×31.9 in
