Specifications | 21
Electrical Specifications
Output Impedance: 50 Ω (nominal)
BNC Connector: For 50-Ω cable
Physical Specifications
Size:
Length: 19.05 cm (7.5 in)
Width: 19.05 cm (7.5 in)
Height: 8.89 cm (3.5 in)
Weight (Antenna base only):
1.4 kg (3.1 lb)
Tripod Mounting: 1/4–20 hole on the base
Monopole Element:
For a finished length of 40.95 in
(1040 mm)—Assemble (2) 116474 rod
sections and (1) 116862.
For a finished length of 39.37 in
(1000 mm)—Assemble (2) 116474 rod
sections. Do not use the 116862 center
section.
See page 26 for the steps to assemble the
monopole.
